InfiRay Outdoor BOLT TL35 V2 Thermal Weapon Sight 384x288 35mm

InfiRay Outdoor BOLT TL35 V2 Thermal Rifle Scope 384x288 35mm.

The InfiRay Outdoor BOLT TL35 V2 was designed for optimal use on any platform that demands flexible mounting options and increased eye relief.

In addition to the features found on the original TL35, the TL35 V2 adds several highly requested features including an AMOLED display, audio recording, and laser rangefinder connectivity via Bluetooth. The T-6061 aluminum housing allows mounting with standard 30 mm rings like a traditional day scope.

A 50hz 12 μm detector, HD display, and manual focus lens all team up to create an image that’s anything but traditional. The TL35 V2 features a dual battery design for 10+ hours of run time and 32GB of internal memory to keep your optic going all night.

The BOLT Series was designed from the ground up for optimal use on bolt action rifles and other platforms that demand flexible mounting options with increased eye relief. The traditional style of a BOLT housing allows for mounting with standard 30mm rings like a typical day scope.

Optics

Objective Lens Material: Germanium
Objective Focal Length: 35mm
Objective F#: 1.1
Optical Magnification: 3X
Detection Range: 1750 Yards
Display Type: AMOLED
Display Resolution: 1024×768
Focusing Mechanism: Manual Focus
Eye Relief: 70mm
Digital Magnification: 4x, stepped
Diopter Range: -4 - +4
Vertical Angular Field of View: 5.7°
Horizontal Angular Field of View: 7.5°
Objective Diameter: 35mm

Environmental Specifications

Recoil Rating: 1000 g/s² (300 Win./7mm Mag)
Ingress Protection: IP67
Operating Temperature Range: -4°F~122°F

Sensor Specifications

Sensor Resolution: 384×288
Sensor Pixel Size: 12μm
Sensor Frame Rate: 50hz
Sensor Type: InfiRay MICRO II
Thermal Sensitivity: <50mk
Non-Uniformity Correction (NUC): Manual, Automatic, Semi-Automatic
Spectral Response: 8-12 Microns
Device Technology: Thermal Imaging

Features & Performance

Rangefinder: Bluetooth ILR-1200-1 LRF (Optional)
Onboard Recording: Yes
Warranty: 5 Years
Picture-in-Picture: Yes
Reticle: 6 (1 Dynamic, 5 Static)
Image Capture: Yes
Mobile App: Yes
Wifi: Yes
Video Output: Analog RS-170/NTSC
Connector Output: Power/Data
Connector Type: USB-C
Color Palettes: White Hot, Black Hot, Red Hot, Color, Highlight
User-Updatable Firmware: Yes
One-Shot Zero: Yes
Stand-by Mode: Yes
Storage Capacity: 32GB
Power Source: Dual Power Supply
Run Time: 8+ hours
External Power Source: USB-C or 18500/18650
Startup Time: Under 10 Seconds
Country of Manufacture: China

Physical

Length: 15.74"
Height: 2.55"
Width: 3.34"
Mounting Interface: 30mm Rings (included)
Housing Material: T-6061 Aluminum
Weight: 32.87 oz

IrayUSA warranty:

5-Year Warranty with a 5-Day Repair Guarantee At iRayUSA we are first and foremost hunters and users of our products and we understand that failure is not an option. One of our primary objectives at iRayUSA is to greatly improve the customer service level for the end user. We plan on accomplishing this through offering our industry-first 1-week repair guarantee, and by only working with highly qualified Authorized Dealers. During the published warranty period, iRayUSA will repair or replace, at its discretion, any optic that becomes defective from normal use. If we cannot repair an optic in less than one week, we will offer a replacement in like or better condition. We know you’ve never seen this from a thermal manufacturer, neither have we, and that’s one of the reasons we started iRayUSA. Our warranty follows the product, and is not tied to the original owner. The warranty period is tied to the date of sale to the dealer or end user registration. This warranty only covers normal use and does not cover cosmetic damage, normal wear, intentional damage, theft, loss, any act of God or a condition caused by use other than intended. Any product that is modified, opened or tampered with will void any warranty coverage. Any serial number damage or alteration on the product will be considered modification. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. One week starts from the time of receipt of product at iRayUSA. Customers must ship the product to iRayUSA, iRayUSA will return the product at no cost. No returns will be accepted without an RMA. iRayUSA is not liable for any damages or loss incurred when shipping to iRayUSA
